Behringer WING Dockhouse Bundle

Bundle offer comprising

Behringer WING

48-Channel Full Stereo Digital Mixer

A new routing approach with an emphasis on sources instead of channels
Fully compatible with Behringer X32 / Midas M32 consoles and stage boxes
Vintage emulations of EQs, compressors and gates available in each of the 40 stereo inputs
40 Stereo inputs
8 Stereo AUX inputs
28 Buses: 16 stereo AUX, 8 stereo matrices, 4 stereo mains
24 Faders in 3 fully programmable sections
10'' Touch display with adjustable angle
Programmable Custom Control section
8 Midas Pro microphone preamp
8 Analog Midas line outputs
8 AUX inputs
6 AUX outputs and 2 monitor outputs: 6.3 mm jack balanced mono
2 Headphone outputs
3 AES50 ports: 48 x 48 channels per port - cable length up to 80 metres
MIDI input/output
2 Programmable GPIOs
48 x 48 Channel USB interface
Expansion slot, including a WING-LIVE card
64 x 64 channel SD recorder/player
StageCONNECT 32-channel port for personal monitoring
16 FX engines: 8 premium, 8 standard
6-Band EQ in the inputs
8-Band EQ in the outputs
Dimensions (H x W x D): 201 x 870 x 575 mm
Weight: 24 kg
Suitable cover available under article no. 480990 (not included, must be ordered separately)
Suitable case available under article no. 499924 (not included, must be ordered separately)
Suitable Dante expansion card available under article no. 512976 (not included, must be ordered separately)

Thon Case Behringer Wing Dockhouse

Roadcase With Dockhouse

Custom-made for Behringer Wing mixing console
The connections are freely accessible - the device can be operated in the lower part
Material: 9 mm Plywood
30 x 30 mm Aluminium edge
4 Spring-loaded medium butterfly latches
4 Spring-loaded large butterfly latches
10 Folding handles
Steel ball corners
Lockable docking housing with dust-protected multicore openings
Foam upholstery made to measure
Roller board with 4 swivel castors - 2 with brakes
2 Skid strips
Exterior dimensions: 940 x 943 x 325 mm
Weight: 38 kg
Colour: Black (RAL 9004)
Made in Germany

30-Day Money-Back Guarantee

3-Year Thomann Warranty

Available since December 2019

Item number 480273

Sales Unit 1 piece(s)

User Interface Physical/remote

Number of faders 24

DSP Input channels 48

Mic Preamp 8

Physical outputs 16

Digital stagebox connection AES50

Hotspot No

Multitrack Record Yes

integratated Player/Rec via USB/SD stereo

19" Rackmount No

DSP Output Channels 16

Busses 28

Mono-Line Input 8

Stereo-Line Input 0

Ethernet Ethernet

Soundcard interface USB-B

Recorder Format WAV

Scribble Strips 1

RTA Yes

FX Processor 16

31 Band EQ 16

Delay Input 1

Delay Output 1

Matrix 8

DCA/VCA Groups 16

Midi Connector Midi-Din

Sample rate 48 kHz

Monitor Apps 1

Separate Personal Monitor system Optional

Expansion Card slots 1

Digital ADAT No

Digital SPDIF No

Digital AES3/ASESEB Yes

Digital MADI No

Digital Dante Optional

110V capable 1

Case Optional

Height 201 mm

Width 870 mm

Depth 575 mm

Weight 24 kg

Show variations of this product

Behringer WING Dockhouse Bundle

Behringer WING Dockhouse Bundle Bundle offer comprising Behringer WING 48-Channel Full Stereo Digital Mixer * A new rout...

50.590 kr

to the product

Behringer WING Rack

Behringer WING Rack 48-Channel Rack Mount Full Stereo Digital Mixer * Fully compatible with Behringer X32/Midas M32 cons...

17.890 kr

to the product

Behringer WING

Behringer WING 48-Channel Full Stereo Digital Mixer * A new routing approach with an emphasis on sources instead of chan...

37.990 kr

to the product

Behringer WING-Bk

Behringer WING-Bk 48-Channel Full Stereo Digital Mixer * New routing concept by focusing on sources instead of channels ...

37.990 kr

to the product

Behringer WING Compact

Behringer WING Compact 48-Channel Full Stereo Digital Mixer * Fully compatible with Behringer X32/Midas M32 consoles and...

30.790 kr

to the product

50.590 kr

Including VAT; Excluding kr290 shipping

Sales Rank

in Digital Mixers

High-performance 48-channel digital mixer

The Behringer Wing is a digital mixing desk with 48 channels that builds on the success of the company’s X32 model. The mixer, which features a user interface with 24 motorised faders and a 10” touchscreen display, also offers mixing afficionados features that include remote control, touch-sensitive rotary controls, high-quality preamps, numerous integrated sound processing plugins, an SD card recorder/player with a marker function, and an optional extension for use in an Ethernet network. A particular feature is that the operating elements can be freely assigned, and stage boxes like the Behringer S16 can also be connected. This bundle includes a robust road case with a docking housing and rollers – Made in Germany, of course.

Extensive connectivity and adaptive flexibility

The mixer is equipped with 40 stereo inputs and an additional eight stereo AUX inputs, while its eight Midas ProSeries preamps ensure a high-quality microphone sound. The input channels feature a six-band EQ unit for signal processing, and the WING also features eight standard effect slots and eight additional premium effects per channel with vintage emulations of equalisers, compressors, reverb units, and more, allowing the sound to be fine-tuned even further. A section with freely programmable control elements allows the Behringer WING to be adjusted to suit your personal workflow. The angle of the display can be adjusted to ensure that it is always legible, and its touchscreen function means that detailed work can be carried out on the mixer in a clear and direct manner. The mixer can be operated in the detachable lower section of the Thon case, and the lockable docking housing also features multicore openings with dust protection.

For beginners and professionals alike

The Behringer WING’s intuitive operation is great news for beginners (though they will still require some knowledge of the basic principles of mixing in order to use it), while advanced users will find the WING to be a high-performance companion which allows them to individually customise their own workflows. This mixer also includes a range of features for professional users, such as mid/side signal processing, AES ports, and compatibility with WAVES Soundgrid and Dante AES67. The faders are arranged in separate sections of four faders each, giving users of all experience levels direct access to the most important channels in their production at all times. Users working with DAWs can control their software using the mixer’s integrated controller function, which is based on Mackie HUI and Mackie Control. The device’s internal designations for assigned audio sources can be renamed using the WING Co-Pilot app and, once they have been entered, these can be used for various routings across the entire device.

About Behringer

The company, which was founded in Germany by Uli Behringer and now manufactures its products in China, has been known for affordable and great-value equipment since its very first product, the Studio Exciter F. An array of mixing consoles (such as the Eurodesk MX8000), signal processors, and later sound amplification and monitoring equipment, has made it possible for countless musicians to fit out their home studios, practice rooms, and mobile PAs within budget limits that were previously unthinkable. The acquisition of other companies, including Midas, Klark Teknik, and TC Electronic, meant that new product groups were added - and also resulted in the technical expertise of these companies being incorporated into product development.

Universal tool for mixing and monitoring

The Behringer WING can be used live as an FOH mixer when combined with Behringer X32 consoles and stage boxes, which keeps the microphone cables short and the signal quality high. When used as part of a network, the WING can operate with cable lengths of up to 80 metres, making it ideal for fixed installation at event locations and as a live mixing desk at medium-sized venues. And the mixer also features a pair of headphone outputs, which means two people can use it simultaneously and makes it perfect for teamwork. Eight line outputs allow the mix signal and sub-mixes to be used for multiple purposes in parallel, such as a main mix, different monitor mixes, and analogue recording. To provide individual monitor mixes, the mixer includes a 32-channel StageCONNECT port to supply compatible devices with sound. The Behringer WING’s “Automix” function automatically regulates preamplification for both active and non-active microphone inputs and thus helps when mixing sound at events with presenters/moderators, at conferences, and in radio broadcasts. Thanks to the robust Thon case’s wheels, the mixer can be transported easily and safely, and the docking housing means it can be operated directly in the case’s lower section.
